Airflow Range: 100 ~ 66,000 m3/h （59～38,824 CFM）

Static Pressure Range: 50～2,100 Pa （0.2～8.4 in.WG）

Drive Types: Direct drive

Mounting Types: Methods: Floor, Hanging, Duct mounted

Applications: Duct supply/exhaust,filter supply/exhaust,low noise cabinet,smoke removal

Certification: AMCA, TUV, CE, ATEX, CNEX, CCCF, EG

Airflow Range:28,440 ~ 252,000 m3/h 16,729~148,235CFM

Thrust Range: 220 ~ 3,000 N

Drive Type: Direct drive

Mounting Types: Ceiling hung/ Sidewall mounted

Applications: Mainly used in tunnels, including metro tunnels, road tunnels, railway tunnels and underground car parks.

Airflow Range: 1,000～380,000 m3/h (588~223,529 CFM)

Static Pressure Range: 300～4,100 Pa (1.2~16.46 in.WG.)

Operating Temperature: -20～450 ℃

Drive Types: Direct/ Belt/ Coupling drive

Mounting Type: Base mounted

Applications: General air supply and exhaust/ Explosion-proof air supply and exhaust / Smoke removal

Certification: AMCA, ATEX, CNEX, CCCF, CE, EG

Airflow Range: 10,000 ~ 980,000 m3/h (5,882 ~ 576,471 CFM)

Total Pressure Range: 50 ~ 2,300 Pa (0.2 ~ 9.23 in.WG.)

Drive Types: Direct drive

Mounting Types: Horizontal/ Vertical

Applications: Metro/ Tunnels/ Construction projects/ Dams, etc.

Airflow Range: 4,000～230,000 m3/h (2,353~135,294 CFM)

Total Pressure Range: 30～2,000 Pa (0.12~8.03 in.WG.)

Drive Type: Direct drive

Mounting Types: Base mounted/ Ceiling hung

Applications: General air supply and exhaust/ Explosion-proof air supply and exhaust / Positive pressure air supply/ Smoke removal

Certification: AMCA, TUV, CNEX, CCCF, EG

Airflow Range: 1,400～130,000 m3/h (824～76,471 CFM)

Static Pressure Range: 100～1,600 Pa (0.4～6.4 in.WG.)

Drive Type: Belt drive

Mounting Methods: Base mounted/ Ceiling hung/ Duct Mounted

Applications: Low sound / Ducted air supply and exhaust of high static pressure/ Filtered air supply and exhaust

Certification: TUV, CNEX, CCCF, EG

Airflow Range: 1,000～100,000 m3/h (588~58,824 CFM)

Static Pressure Range: 1,000～2,150 Pa (4~8.63 in.WG.)

Drive Types: Direct/ Belt drive

Mounting Types: Roof mounted / Base mounted / Ceiling hung

Applications: Ducted air supply and exhaust / Explosion-proof air supply and exhaust / Positive pressure air supply/ Smoke removal

Certification: AMCA, CCCF, CNEX, TUV, EG

Airflow range: 500～212,000 m3/h（295～124,706 CFM）

Static pressure range: 5～1,370Pa（0.02～5.48 in.WG）

Drive type: direct drive

Installation Methods: floor mounted, hanging or ducted

Application: General air supply& exhaust, explosion-proof supply& exhaust, positive pressure air supply, Smoke removal duty

Certification: CNEX,CCCF.EG

Airflow Range: 2,600～116,800 m3/h (1,529～68,706 CFM)

Static Pressure Range: 50～850 Pa (0.2～3.41 in.WG.)

Drive Configurations: Direct

Installation Methods: Vertical/ Horizontal/ Ceiling Hung

Applications: Fire & Smoke/ Two-Speed Fume Extraction

Certification: CCCF, EG

Airflow Range: 300～52,000 m3/h (176～30,588 CFM)

Static Pressure Range: 100～700 Pa (0.4～2.81 in.WG.)

Drive Types: Direct/ Belt drive

Mounting Types: Rooftop

Applications: Rooftop ventilation / Explosion proof air supply and exhaust / Smoke removal

Certification: AMCA, TUV, CNEX, CCCF

Airflow range: 300 ~52,000 m3/h (176～30,588 CFM)

Static pressure range: 100 ~ 700Pa (0.4～2.8 in.WG.)

Drive type: Direct drive, Belt drive

Installation methods: Rooftop curb mounted

Application: Chinese and western fast food restaurant, Electronics, automobile industry welding fume exhaust, Laboratory exhaust, Odor or VOC contaminated air exhaust and explosion-proof exhaust

Airflow Range: 10～152,000 m3/h (6～89,412 CFM)

Static Pressure Range: 0～700 Pa (0～2.81 in.WG.)

Drive Type: Direct

Installation Methods: Rooftop

Applications: Rooftop/ Explosion Resistant/ Fire & Smoke

Certification: CNEX, CCCF
