Airflow Range: 100 ~ 66,000 m3/h （59～38,824 CFM）

Static Pressure Range: 50～2,100 Pa （0.2～8.4 in.WG）

Drive Types: Direct drive

Mounting Types: Methods: Floor, Hanging, Duct mounted

Applications: Duct supply/exhaust,filter supply/exhaust,low noise cabinet,smoke removal

Certification: AMCA, TUV, CE, ATEX, CNEX, CCCF, EG

Airflow Range: 1,000～380,000 m3/h (588~223,529 CFM)

Static Pressure Range: 300～4,100 Pa (1.2~16.46 in.WG.)

Operating Temperature: -20～450 ℃

Drive Types: Direct/ Belt/ Coupling drive

Mounting Type: Base mounted

Applications: General air supply and exhaust/ Explosion-proof air supply and exhaust / Smoke removal

Certification: AMCA, ATEX, CNEX, CCCF, CE, EG

Airflow Range: 4,000～230,000 m3/h (2,353~135,294 CFM)

Total Pressure Range: 30～2,000 Pa (0.12~8.03 in.WG.)

Drive Type: Direct drive

Mounting Types: Base mounted/ Ceiling hung

Applications: General air supply and exhaust/ Explosion-proof air supply and exhaust / Positive pressure air supply/ Smoke removal

Certification: AMCA, TUV, CNEX, CCCF, EG

Airflow Range: 1,400～130,000 m3/h (824～76,471 CFM)

Static Pressure Range: 100～1,600 Pa (0.4～6.4 in.WG.)

Drive Type: Belt drive

Mounting Methods: Base mounted/ Ceiling hung/ Duct Mounted

Applications: Low sound / Ducted air supply and exhaust of high static pressure/ Filtered air supply and exhaust

Certification: TUV, CNEX, CCCF, EG

Airflow range: 0 ~ 1,700 m3/h （0～170 CFM）

Static pressure range: 40～800 Pa （0.16～3.2 in.WG）

Drive Configurations: Direct

Installation methods: Duct mounted

Application: Small volume incline supply/exhaust, office and meeting room supply/exhaust

Certification: CE.EG

Airflow Range: 1,000～100,000 m3/h (588~58,824 CFM)

Static Pressure Range: 1,000～2,150 Pa (4~8.63 in.WG.)

Drive Types: Direct/ Belt drive

Mounting Types: Roof mounted / Base mounted / Ceiling hung

Applications: Ducted air supply and exhaust / Explosion-proof air supply and exhaust / Positive pressure air supply/ Smoke removal

Certification: AMCA, CCCF, CNEX, TUV, EG

Airflow range: 500～212,000 m3/h（295～124,706 CFM）

Static pressure range: 5～1,370Pa（0.02～5.48 in.WG）

Drive type: direct drive

Installation Methods: floor mounted, hanging or ducted

Application: General air supply& exhaust, explosion-proof supply& exhaust, positive pressure air supply, Smoke removal duty

Certification: CNEX,CCCF.EG

Airflow Range: 2,600～116,800 m3/h (1,529～68,706 CFM)

Static Pressure Range: 50～850 Pa (0.2～3.41 in.WG.)

Drive Configurations: Direct

Installation Methods: Vertical/ Horizontal/ Ceiling Hung

Applications: Fire & Smoke/ Two-Speed Fume Extraction

Certification: CCCF, EG

Airflow Range: 1,000 ~ 220,000 m3/h (588 ~ 129,412 CFM)

Total Pressure Range: 300 ~ 5,400 Pa (1.2 ~ 21.68 in.WG.)

Operating Temperature: -20～450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 500～56,000 m3/h (294～32,941CFM)

Static Pressure Range: 136～1,400 Pa (0.55～5.62 in.WG.)

Drive Type: Belt/ Direct drive

Mounting Types: Base Mount/ Ceiling Hung

Applications: Industrial ventilation / Explosion proof air exhaust / Kitchen fume exhaust

Certification: AMCA, CE, CNEX, EG

Airflow Range: 1,500 ~ 201,000 m3/h (882 ~ 118,235 CFM)

Total Pressure Range: 475～10,900 Pa (1.91～43.76 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 1,000 ~ 260,000 m3/h (588 ~ 152,941 CFM)

Total Pressure Range: 200 ~ 3,150 Pa (0.8 ~ 12.65 in.WG.)

Drive Types: Belt drive

Applications: AHU fans, HVAC fans, air purifier fans and ventilation fans among others

Certification: AMCA, EG

Airflow Range: 1,000 ~ 266,000 m3/h (588~156,471 CFM)

Total Pressure Range: 500 ~ 7,400 Pa (2.01~29.71 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Configurations: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certifications: AMCA, CNEX, ATEX, CE, EG

Airflow Range: 500 ~ 66,000 m3/h (294 ~38,824 CFM)

Total Pressure Range: 1,000 ~ 19,000 Pa (4.01 ~76.28 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Configurations: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 500 ~ 125,000 m3/h (294 ~ 73,529 CFM )

Total Pressure Range: 300～11,500 Pa (1.2 ~ 46.17 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 1,000 ~ 144,000 m3/h (588 ~ 84,706 CFM)

Total Pressure Range: 1,000 ~ 17,000 Pa (4.01 ~ 68.25 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion resistant. Suitable for extracting fume and vapour from environment

Certification: CE, CNEX, EG
